Cathedral Church of St. Edmundsbury, Bury St Edmunds, Suffolk
History:
Harrison & Harrison, Durham 2010 incorporating pipework from the former Nicholson, Norman & Beard and Walker organs
Casefronts based on designs by Stephen Dykes Bower
Great:
Double Open Diapason - 16*
Open Diapason No. 1 - 8*
Open Diapason No. 2 - 8*
Stopped Diapason - 8* wood
Principal - 4*
Chimney Flute - 4
Twelfth - 22/3
Fifteenth - 2
Mixture - V
Trombone - 16*
Trumpet - 8*
Clarion - 4*
Swell:
Bourdon - 16
Open Diapason - 8
Lieblich Gedackt - 8
Echo Gamba - 8
Voix Céleste(tenor c) - 8 from c
Principal - 4
Flute - 4
Fifteenth - 2
Sesquialtera - II
Mixture - IV
Contra Fagotto - 16*
Cornopean - 8
Oboe - 8
Clarion - 4*
Tremulant
Choir:
Open Diapason - 8*
Stopped Flute - 8
Principal - 4
Nason Flute - 4*
Nazard - 22/3
Fifteenth - 2
Flautino - 2*
Tierce - 13/5
Sifflöte - 1
Cremona - 8*
Tremulant
Solo:
Quintaton - 8 bass from Swell Bourdon
Viole d'Orchestre - 8
Viole Cèleste - 8 from c
Harmonic Flute - 8*
Flauto Traverso - 4*
Clarinet - 8
Vox Humana - 8*
Tuba - 8*
Orchestral Trumpet - 4*
Tremulant
Pedal:
Contra Bass - 32 from Sub Bass
Open Wood - 16
Open Diapason - 16*
Violone - 16* from Great Double Open Diapason
Sub Bass - 16
Echo Bourdon - 16 from Swell Bourdon
Principal - 8
Bass Flute - 8 from Sub Bass
Fifteenth - 4
Mixture - IV
Double Trombone - 32 from Great Trombone
Ophicleide - 16*
Trombone - 16* " " "
Fagotto - 16* from Swell Contra Fagotto
*new stops
Couplers:
Swell Octave
Swell Suboctave
Swell unison off
Solo Octave
Solo Suboctave
Solo Unison off
Swell to Great
Choir to Great
Solo to Great
Swell to Choir
Solo to Choir
Solo to Swell
Swell to Pedal
Great to Pedal
Choir to Pedal
Solo to Pedal
Great Reeds on Pedal
Great Reeds on choir
Compass:
manual: C - c '''' 61 notes
pedal: C - g ' 32 notes
Accessories:
2 general pistons to general-cancel
2 general coupler pistons
8 thumb pistons to Choir
8 thumb pistons to Great
8 thumb pistons to Swell
6 thumb pistons to Solo
8 toe pistons to Pedal
Great & Pedal pistons coupled
generals on Swell toe pistons
manuals I & II exchange
reversible pistons to:
Pedal couplers, Swell to Choir, Solo to Choir, Choir to Great, Swell to Great, Solo to Great and Solo to Swell reversible toe pistons: Choir to Pedal, Great to Pedal, Swell to Pedal, Swell to Choir, Sweel to Great, Contra Bass and Double Trombone
8 divisional and 128 general memory levels
stepper operating general pistons in sequence
balanced swell pedals to Swell (Transept), Swell (Quire), and Solo
